A choke is the common name given to an inductor that is used as a power supply filter element. It is an inductor used to block higher-frequency alternating current (AC) in an electrical circuit, while passing lower-frequency or direct current (DC). A choke usually consists of a coil of insulated wire and they are typically gapped iron core units, similar in appearance to a small transformer, but with only two leads exiting the housing. The current in an inductor cannot change instantaneously that is inductors tend to resist any change in current flow. This property makes them good for use as filter elements, since they tend to smooth out the ripples in the rectified voltage waveform. The choke’s impedance rises with frequency. Its low electrical resistance passes both AC and DC with little power loss, but it can limit the amount of AC owing to its reactance. A choke is used in position of a series resistor because the choke allows superior filtering and less voltage drop.
More about this can be seen in Eric Bogatin’s post on EDN where he comes up with a nice rule of thumb:
If you were to picture multiple traces in the same dielectric space you can see that the fields would overlap and consequently interact with each other. This is one of the primary causes of crosstalk. Another way of saying this is that crosstalk occurs in the whitespace between the conductors where the fields overlap and interact.
